View fgh20n60ufd datasheet:

April 2011FGH20N60UFD600V, 20A Field Stop IGBTFeatures General Description High current capability Using Novel Field Stop IGBT Technology, Fairchilds new seriesof Field Stop IGBTs offer the optimum performance for Induc- Low saturation voltage: VCE(sat) =1.8V @ IC = 20Ation Heating, UPS, SMPS and PFC applications where low con- High input impedanceduction and switching losses are essential. Fast switching RoHS compliantApplications Induction Heating, UPS, SMPS, PFCECCGGCOLLECTOR(FLANGE) EAbsolute Maximum RatingsSymbol Description Ratings UnitsVCES Collector to Emitter Voltage 600 VVGES Gate to Emitter Voltage 20 VCollector Current @ TC = 25oC 40 AICCollector Current @ TC = 100oC 20 AICM (1) Pulsed Collector Current 60 A@ TC = 25oC Diode Forward Current @ TC = 25oC 20 AIFDiode Forward Current @ TC
