March 2009FGH40N60SFtm600V, 40A Field Stop IGBTFeatures General Description High current capability Using Novel Field Stop IGBT Technology, Fairchilds new ses-ries of Field Stop IGBTs offer the optimum performance for Low saturation voltage: VCE(sat) =2.3V @ IC = 40AInverter, UPS, SMPS and PFC applications where low conduc- High input impedancetion and switching losses are essential. Fast switching RoHS compliantApplications Inverter, UPS, SMPS, PFCECGCOLLECTOR(FLANGE)Absolute Maximum RatingsSymbol Description Ratings UnitsVCES Collector to Emitter Voltage 600 VVGES Gate to Emitter Voltage 20 VCollector Current @ TC = 25oC80 AICCollector Current @ TC = 100oC40 AICM (1) Pulsed Collector Current 120 A@ TC = 25oC Maximum Power Dissipation @ TC = 25oC290 WPDMaximum Power Dissipation @ TC = 100oC116 Wo
