View fgh40n60smd datasheet:
November 2010FGH40N60SMD600V, 40A Field Stop IGBTFeatures General Description Maximum Junction Temperature : TJ =175oC Using Novel Field Stop IGBT Technology, Fairchilds new seriesof Field Stop IGBTs offer the optimum performance for Solar Positive Temperaure Co-efficient for easy parallel operatingInverter, UPS, Welder and SMPS applications where low con- High current capabilityduction and switching losses are essential. Low saturation voltage: VCE(sat) =1.9V(Typ.) @ IC = 40A High input impedance Fast switching Tighten Parameter Distribution RoHS compliantApplications Solar Inverter UPS, Welder, SMPSECCGGCOLLECTOR(FLANGE) EAbsolute Maximum RatingsSymbol Description Ratings UnitsVCES Collector to Emitter Voltage 600 VVGES Gate to Emitter Voltage 20 VCollector Current @ TC = 25oC 80 AICCo
