View fgh40n60ufd datasheet:

April 2009FGH40N60UFDtm600V, 40A Field Stop IGBTFeatures General Description High current capability Using Novel Field Stop IGBT Technology, Fairchilds new ses-ries of Field Stop IGBTs offer the optimum performance for Low saturation voltage: VCE(sat) =1.8V @ IC = 40AInduction Heating, UPS, SMPS and PFC applications where low High input impedanceconduction and switching losses are essential. Fast switching RoHS compliantApplications Induction Heating, UPS, SMPS, PFCECCGGCOLLECTOR(FLANGE)EAbsolute Maximum RatingsSymbol Description Ratings UnitsVCES Collector to Emitter Voltage 600 VVGES Gate to Emitter Voltage 20 VCollector Current @ TC = 25oC80 AICCollector Current @ TC = 100oC40 AICM (1) Pulsed Collector Current @ TC = 25oC 120 AIF Diode Continuous Forward Current @ TC = 25oC 40 ADiode Continuous
