View fgh60n60sf datasheet:

July 2008FGH60N60SFtm600V, 60A Field Stop IGBTFeatures General Description High current capability Using Novel Field Stop IGBT Technology, Fairchilds new seriesof Field Stop IGBTs offer the optimum performance for Induction Low saturation voltage: VCE(sat) =2.3V @ IC = 60AHeating, UPS, SMPS and PFC applications where low conduc- High input impedancetion and switching losses are essential. Fast switching RoHS compliantApplications Induction Heating, UPS, SMPS, PFCECGCOLLECTOR(FLANGE)Absolute Maximum RatingsSymbol Description Ratings UnitsVCES Collector to Emitter Voltage 600 VVGES Gate to Emitter Voltage 20 VCollector Current @ TC = 25oC120 AICCollector Current @ TC = 100oC60 AICM (1) Pulsed Collector Current 180 A@ TC = 25oC Maximum Power Dissipation @ TC = 25oC378 WPDMaximum Power Dissipation @ TC
