View fgl35n120ftd datasheet:
February 2010FGL35N120FTDtm1200V, 35A Trench IGBTFeatures General Description Field Stop Trench Technology Using advanced field stop trench technology, Fairchilds 1200Vtrench IGBTs offer superior conduction and switching perfor- High Speed Switchingmances, and easy parallel operation with exceptional avalanche Low Saturation Voltage: VCE(sat) = 1.68 V @ IC = 35Aruggedness. This device is designed for soft switching applica- High Input Impedancetions.Applications Induction Heating And Microwave Oven Soft Switching ApplicationsCGEAbsolute Maximum RatingsSymbol Description Ratings UnitsVCES Collector to Emitter Voltage 1200 VVGES Gate to Emitter Voltage 25 VCollector Current 70 A@ TC = 25oCICCollector Current 35 A@ TC = 100oCICM (1) Pulsed Collector Current 105 A@ TC = 25oC IF 40 ADiode Continuous Forwa
