View fgy75n60smd datasheet:

June 2014FGY75N60SMD600 V, 75 A Field Stop IGBTFeatures General Description High Current Capability Using novel field stop IGBT technology, Fairchilds new series of field stop 2nd generation IGBTs offer the optimum perfor- Low Saturation Voltage: VCE(sat) = 1.9 V @ IC = 75 Amance for solar inverter, UPS, welder and PFC applications High Input Impedancewhere low conduction and switching losses are essential. Fast Switching : EOFF = 10 uJ/A RoHS CompliantApplication Solar Inverter, UPS, Welder, SMPS, PFCCGGEPower TO247C(TO-247D03)EAbsolute Maximum RatingsSymbol Description Ratings UnitVCES Collector to Emitter Voltage 600 VGate to Emitter Voltage 20 VVGESTransient Gate to Emitter Voltage 30 VCollector Current @ TC = 25oC 150 AICCollector Current @ TC = 100oC 75 AICM (1) Pulsed Collector Current 225
