View fhp10n60a fhf10n60a datasheet:

N N-CHANNEL MOSFET FHP10N60A/ FHF10N60A MAIN CHARACTERISTICS FEATURES Low gate charge ID 10A Crss ( 23pF) Low Crss (typical 23pF ) VDSS 600V Fast switching Rdson-typ 0.68 @Vgs=10V 100% 100% avalanche tested Qg-typ 45nC dv/dt Improved dv/dt capability RoHS RoHS product APPLICATION High efficiency switch mode power supplies Electronic ballastLED LED power supply Package Equivalent CircuitTO-220FTO-220FHF FHP ABSOLUTE RATINGS (Tc=25 ) Value Parameter SymbolFHP10N60A FHF10N60A Unit VDS 600 VDrain-Source Voltage * ID TC=25 10* ADrain Current -continuous * ID TC=100 ) 6.2* A 1 IDM 40* ADrain Current pulse note 1 VGS 20 VGate-Source Voltage 2 EAS 600 mJSingle Pulsed Avalanche Energy n
