View h2n5401 datasheet:

h2n5401h2n5401

Spec. No. : HE6203HI-SINCERITYIssued Date : 1992.09.22Revised Date : 2005.01.20MICROELECTRONICS CORP.Page No. : 1/5H2N5401PNP EPITAXIAL PLANAR TRANSISTORDescriptionThe H2N5401 is designed for general purpose applications requiring highbreakdown voltages.TO-92Features Complements to NPN Type H2N5551 High Collector-Emitter Breakdown Voltage (VCEO=150V (@IC=1mA))Absolute Maximum Ratings Maximum TemperaturesStorage Temperature ........................................................................................................................... -55 ~ +150 CJunction Temperature ................................................................................................................... +150 C Maximum Maximum Power DissipationTotal Power Dissipation (TA=25C) ..................................................................
