S E M I C O N D U C T O R HGTP14N40F3VL14A, 400V N-Channel,Logic Level Voltage Clamping IGBTApril 1995Features Package Logic Level Gate DriveJEDEC TO-220AB Internal Voltage ClampEMITTERCOLLECTOR ESD Gate ProtectionGATE TJ = +150oCCOLLECTOR(FLANGE) Ignition Energy CapableApplications Automotive Ignition Small Engine Ignition Fuel IgnitorSymbolDescriptionCOLLECTORThis N-Channel IGBT is a MOS gated, logic level device which isintended to be used as an ignition coil driver in automotive ignitioncircuits. Unique features include an active voltage clamp betweenthe drain and the gate and ESD protection for the logic level gate.Some specifications are unique to this automotive application andGATEare intended to assure device survival in this harsh environment.The development type number for this device is TA49
