View hgtp15n4 datasheet:

HGTP15N40C1, 40E1, 50C1, 50E1,S E M I C O N D U C T O R HGTH20N40C1, 40E1, 50C1, 50E115A, 20A,400V and 500V N-Channel IGBTsApril 1995Features PackagesHGTH-TYPES JEDEC TO-218AC 15A and 20A, 400V and 500VEMITTER VCE(ON) 2.5VCOLLECTOR TFI 1s, 0.5sGATECOLLECTOR(FLANGE) Low On-State Voltage Fast Switching Speeds High Input Impedance No Anti-Parallel DiodeApplicationsHGTP-TYPES JEDEC TO-220AB Power Supplies Motor DrivesEMITTERCOLLECTORCOLLECTOR(FLANGE) Protection CircuitsGATEDescriptionThe HGTH20N40C1, HGTH20N40E1, HGTH20N50C1, HGTH20N50E1,HGTP15N40C1, HGTP15N40E1, HGTP15N50C1 and HGTP15N50E1are n-channel enhancement-mode insulated gate bipolar transistors(IGBTs) designed for high-voltage, low on-dissipation applications such asswitching regulators and motor drivers. These types can be oper
