View irf1503 datasheet:

PD-94526AAUTOMOTIVE MOSFETIRF1503Typical ApplicationsHEXFET Power MOSFET 14V Automotive Electrical SystemsD 14V Electronic Power SteeringVDSS = 30VFeatures Advanced Process TechnologyRDS(on) = 3.3m Ultra Low On-ResistanceG 175C Operating Temperature Fast Switching ID = 75AS Repetitive Avalanche Allowed up to TjmaxDescriptionSpecifically designed for Automotive applications, thisdesign of HEXFET Power MOSFETs utilizes the lastestprocessing techniques to achieve extremely low on-resistance per silicon area. Additional features of thisHEXFET power MOSFET are a 175C junction operatingtemperature, fast switching speed and improved repetitiveavalanche rating. These combine to make this design anextremely efficient and reliable device for use in Automotiveapplications and a wide variety of other application
