View irf1607 datasheet:

irf1607irf1607

isc N-Channel MOSFET Transistor IRF1607IIRF1607FEATURESStatic drain-source on-resistance:RDS(on) 7.5mEnhancement modeFast Switching Speed100% avalanche testedMinimum Lot-to-Lot variations for robust deviceperformance and reliable operationDESCRITIONreliable device for use in a wide variety of applicationsABSOLUTE MAXIMUM RATINGS(T =25)aSYMBOL PARAMETER VALUE UNITV Drain-Source Voltage 75 VDSSV Gate-Source Voltage 20 VGSI Drain Current-Continuous 142 ADI Drain Current-Single Pulsed 570 ADMP Total Dissipation @T =25 380 WD CT Max. Operating Junction Temperature 175 jT Storage Temperature -55~175 stgTHERMAL CHARACTERISTICSSYMBOL PARAMETER MAX UNITChannel-to-case thermal resistance/WRth(ch-c) 0.40Channel-to-ambient thermal resistance/WRth(ch-a) 621isc websitewww.is
