View irf2204lpbf irf2204spbf datasheet:

PD - 95491AIRF2204SPbFTypical Applications IRF2204LPbF Industrial Motor DriveHEXFET Power MOSFETDFeaturesVDSS = 40V Advanced Process Technology Ultra Low On-Resistance Dynamic dv/dt Rating RDS(on) = 3.6mG 175C Operating Temperature Fast SwitchingID = 170A Repetitive Avalanche Allowed up to TjmaxS Lead-FreeDescriptionThis HEXFET Power MOSFET utilizes the lastestprocessing techniques to achieve extremely low on-resistance per silicon area. Additional features of thisdesign are a 175C junction operating temperature,fast switching speed and improved repetitiveavalanche rating. These features combine to makeD2Pak TO-262this design an extremely efficient and reliable deviceIRF2204SPbF IRF2204LPbFfor use in a wide variety of applications.Absolute Maximum RatingsParameter Max. UnitsID @ TC = 25C Continuous Drain Cur
