View irf2204pbf datasheet:
PD - 95490AIRF2204PbFTypical ApplicationsHEXFET Power MOSFET Industrial Motor DriveDFeaturesVDSS = 40V Advanced Process Technology Ultra Low On-ResistanceRDS(on) = 3.6m Dynamic dv/dt RatingG 175C Operating TemperatureID = 210A Fast SwitchingS Repetitive Avalanche Allowed up to Tjmax Lead-FreeDescriptionThis HEXFET Power MOSFET utilizes the lastestprocessing techniques to achieve extremely low on-resistance per silicon area. Additional features of thisdesign are a 175C junction operating temperature,fast switching speed and improved repetitiveavalanche rating. These features combine to makeTO-220ABthis design an extremely efficient and reliable devicefor use in a wide variety of applications.Absolute Maximum RatingsParameter Max. UnitsID @ TC = 25C Continuous Drain Current, VGS @ 10V 210ID @ TC = 100C
