View irf3546m datasheet:

irf3546mirf3546m

60A Dual Integrated Power Block IRF3546 The IRF3546 dual integrated Power Block co-FEATURES packages two pairs of high performance control and synchronous MOSFETs and is ideal for use in high- Peak efficiency up to 94% at 1.2V density two-phase synchronous buck converters. It is Two pairs of control and synchronous optimized internally for PCB layout, heat transfer and MOSFETs in a single PQFN package package inductance. Coupled with the latest generation of IR MOSFET technology, the IRF3546 Proprietary package minimizes package provides higher efficiency at low output voltages parasitic and simplifies PCB layout required by cutting edge CPU, GPU and DDR Input voltage (VIN) range of 4.5V to 21V memory designs. Output current capability of 30A/phase High switching frequency enables high performance Ultra-low Rg MOSFET tec
