View irf460b irf460c datasheet:

irf460b_irf460cirf460b_irf460c

RoHS IRF460 Series RoHS SEMICONDUCTORNell High Power ProductsN-Channel Power MOSFET20A, 500VoltsDESCRIPTIOND The Nell IRF460 is a three-terminal silicon devicewith current conduction capability of 20A, fast switchingspeed, low on-state resistance, breakdown voltagerating of 500V, and max. threshold voltage of 4 volts. They are designed for use in applications such as GGDswitched mode power supplies, DC to DC converters,SDmotor control circuits UPS and general purpose STO-3PBTO-247ABswitching applications. (IRF450B)(IRF460C)D (Drain) FEATURES RDS(ON) = 0.27 @ VGS = 10V G Ultra low gate charge(210nC Max.)(Gate)Low reverse transfer capacitanceS (Source)(CRSS = 350pF typical)Fast switching capabilityPRODUCT SUMMARY100% avalanche energy specifiedID (A)Improved dv/dt capability 20150C operation temperature
