View irf630s datasheet:

IRF630Swww.VBsemi.twPower MOSFETFEATURESPRODUCT SUMMARY Halogen-free According to IEC 61249-2-21VDS (V) 200DefinitionRDS(on) ()VGS = 10 V 0.30 Surface MountQg (Max.) (nC) 43 Available in Tape and ReelQgs (nC) 7.0 Dynamic dV/dt RatingQgd (nC) 23 Repetitive Avalanche RatedConfiguration Single Fast Switching Ease of Paralleling Simple Drive Requirements Compliant to RoHS Directive 2002/95/ECDD2PAK (TO-263)KGSDGSN-Channel MOSFET ABSOLUTE MAXIMUM RATINGS (TC = 25 C, unless otherwise noted)PARAMETER SYMBOL LIMIT UNITDrain-Source Voltage VDS 200V Gate-Source Voltage VGS 20TC = 25 C 10Continuous Drain Current VGS at 10 V IDTC = 100 C 6.7 APulsed Drain Currenta IDM 36Linear Derating Factor 0.59W/C Linear Derating Factor (PCB Mount)e 0.025Single Pulse Avalanche Energyb EA
