View irf840 1 datasheet:

irf840_1irf840_1

Philips Semiconductors Product specification PowerMOS transistor IRF840 Avalanche energy ratedFEATURES SYMBOL QUICK REFERENCE DATAd Repetitive Avalanche Rated Fast switching VDSS = 500 V High thermal cycling performance Low thermal resistance ID = 8.5 AgRDS(ON) 0.85 sGENERAL DESCRIPTION PINNING SOT78 (TO220AB)N-channel, enhancement mode PIN DESCRIPTIONtabfield-effect power transistor,intended for use in off-line switched 1 gatemode power supplies, T.V. andcomputer monitor power supplies, 2 draind.c. to d.c. converters, motor controlcircuits and general purpose 3 sourceswitching applications.tab drain1 2 3The IRF840 is supplied in theSOT78 (TO220AB) conventionalleaded package.LIMITING VALUESLimiting values in accordance with the Absolute Maximum System (IEC 134)SYMBOL PARAMETER CONDITIONS MIN. MAX. UNITVDSS
