View irf840lc datasheet:

irf840lcirf840lc

INCHANGE Semiconductorisc N-Channel MOSFET Transistor IRF840LCFEATURESWith low gate drive requirementsUltra low gate chargeExtremely high frequency operation100% avalanche testedMinimum Lot-to-Lot variations for robust deviceperformance and reliable operationAPPLICATIONSSwitching applicationsFor DC-DC converterABSOLUTE MAXIMUM RATINGS(T =25)aSYMBOL PARAMETER VALUE UNITV Drain-Source Voltage 500 VDSSV Gate-Source Voltage 30 VGSSDrain Current-Continuous@T =25C 8.0I AD5.1T =100CI Drain Current-Single Pulsed 28 ADMP Total Dissipation 125 WDT Operating Junction Temperature -55~150 jT Storage Temperature -55~150 stgTHERMAL CHARACTERISTICSSYMBOL PARAMETER MAX UNIT/WRth(ch-c) Channel-to-case thermal resistance 0.5/WRth(ch-a) Channel-to-ambient thermal resistance 621is
