View irf840s datasheet:

irf840sirf840s

IRF840SRoHS-compliant ProductAdvanced Power N-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET Ease of Paralleling D BVDSS 500V Fast Switching Characteristic RDS(ON) 0.85 Simple Drive Requirement ID 8AGSDescriptionAPEC MOSFET provide the power designer with the best combination of fastGswitching , lower on-resistance and reasonable cost.DS TO-263(S)The TO-263 package is widely preferred for commercial-industrial surfacemount applications and suited for low voltage applications such as DC/DCconverters.Absolute Maximum RatingsSymbol Parameter Rating UnitsVDS Drain-Source Voltage 500 VVGS Gate-Source Voltage +20 VID@TC=25 Continuous Drain Current, VGS @ 10V 8 AID@TC=100 Continuous Drain Current, VGS @ 10V 5.1 AIDM Pulsed Drain Current1 32 APD@TC=25 Total Power Dissipation 125 W EAS Single Pulse Avalanche Energy
