View irf9540ns datasheet:
PD - 91483DIRF9540NS/LHEXFET Power MOSFETl Advanced Process TechnologyDl Surface Mount (IRF9540S)VDSS = -100Vl Low-profile through-hole (IRF9540L)l 175C Operating TemperatureRDS(on) = 0.117l Fast SwitchingGl P-ChannelID = -23Al Fully Avalanche RatedSDescriptionFifth Generation HEXFETs from International Rectifier utilizeadvanced processing techniques to achieve extremely lowon-resistance per silicon area. This benefit, combined withthe fast switching speed and ruggedized device design thatHEXFET Power MOSFETs are well known for, provides thedesigner with an extremely efficient and reliable device foruse in a wide variety of applications.The D2Pak is a surface mount power package capable ofaccommodating die sizes up to HEX-4. It provides the highestpower capability and the lowest possible on-resistance in Pak TO-262any exis
