View irfb31n20dpbf irfs31n20dpbf irfsl31n20dpbf datasheet:

irfb31n20dpbf_irfs31n20dpbf_irfsl31n20dpbfirfb31n20dpbf_irfs31n20dpbf_irfsl31n20dpbf

IRFB31N20DPbFSMPS MOSFETIRFS31N20DPbFIRFSL31N20DPbFAppIications HEXFET Power MOSFETl High Frequency DC-DC convertersl Lead-FreeVDSS RDS(on) max ID200V 0.082 31ABenefitsl Low Gate to Drain to Reduce SwitchingLossesl Fully Characterized Capacitance IncludingEffective COSS to Simplify Design,(SeeAN 1001)l Fully Characterized Avalanche Voltageand CurrentTO-220AB D2Pak TO-262IRFB31N20DPbF IRFS31N20DPbF IRFSL31N20DPbFAbsolute Maximum RatingsParameter Max. UnitsID @ TC = 25C Continuous Drain Current, VGS @ 10V 31ID @ TC = 100C Continuous Drain Current, VGS @ 10V 21 AIDM Pulsed Drain Current 124PD @TA = 25C Power Dissipation 3.1 WPD @TC = 25C Power Dissipation 200Linear Derating Factor 1.3 W/CVGS Gate-to-Source Voltage 30 Vdv/dt Peak Diode Recovery dv/dt 2.1 V/nsTJ Operating Junction and -55 to + 1
