View irfb38n20dpbf irfs38n20dpbf datasheet:
PD - 97001CIRFB38N20DPbF IRFS38N20DPbF IRFSL38N20DPbFHEXFET Power MOSFETApplicationsKey Parametersl High frequency DC-DC convertersVDS200 Vl Plasma Display PanelVDS (Avalanche) min.260 VBenefitsRDS(ON) max @ 10V m54l Low Gate-to-Drain Charge toTJ max175 CReduce Switching Lossesl Fully Characterized CapacitanceIncluding Effective COSS to SimplifyDesign, (See App. Note AN1001)l Fully Characterized Avalanche Voltageand CurrentD2Pak TO-262TO-220ABl Lead-FreeIRFS38N20DPbF IRFSL38N20DPbFIRFB38N20DPbFAbsolute Maximum RatingsParameter Max. UnitsID @ TC = 25C Continuous Drain Current, VGS @ 10V 43*ID @ TC = 100C Continuous Drain Current, VGS @ 10V 30* AIDM Pulsed Drain Current 180PD @TA = 25C Power Dissipation 3.8 WPD @TC = 25C Power Dissipation 300*Linear Derating Factor 2.0* W/CVGS
