View irfbc30a datasheet:
PD - 95700SMPS MOSFETIRFBC30APbFHEXFET Power MOSFETApplicationsVDSS Rds(on) max IDl Switch Mode Power Supply (SMPS)l Uninterruptable Power Supply 600V 2.2 3.6Al High speed power switchingl Lead-FreeBenefitsl Low Gate Charge Qg results in SimpleDrive Requirementl Improved Gate, Avalanche and dynamicdv/dt Ruggednessl Fully Characterized Capacitance and Avalanche Voltage and CurrentG D STO-220ABl Effective Coss specified (See AN 1001)Absolute Maximum RatingsParameter Max. UnitsID @ TC = 25C Continuous Drain Current, VGS @ 10V 3.6ID @ TC = 100C Continuous Drain Current, VGS @ 10V 2.3 AIDM Pulsed Drain Current 14PD @TC = 25C Power Dissipation 74 WLinear Derating Factor 0.69 W/CVGS Gate-to-Source Voltage 30 Vdv/dt Peak Diode Recovery dv/dt 7.0 V/nsTJ Operating Junction and -55 to + 150TSTG Storage Temperature Ra
