View irfp150a datasheet:

irfp150airfp150a

INCHANGE Semiconductorisc N-Channel MOSFET Transistor IRFP150AFEATURESDrain Current I = 43A@ T =25D CDrain Source Voltage-: V = 100V(Min)DSSStatic Drain-Source On-Resistance: R = 0.04(Max)DS(on)Fast Switching100% testedMinimum Lot-to-Lot variations for robust deviceperformance and reliable operationDESCRIPTIONDesigned for use in switch mode power supplies and generalpurpose applications.ABSOLUTE MAXIMUM RATINGS(T =25)aSYMBOL PARAMETER VALUE UNITV Drain-Source Voltage 100 VDSSV Gate-Source Voltage-Continuous 20 VGSI Drain Current-Continuous 43 ADI Drain Current-Single Pluse 170 ADMP Total Dissipation @T =25 193 WD CMax. Operating Junction Temperature -55~150 TJT Storage Temperature -55~150 stgTHERMAL CHARACTERISTICSSYMBOL PARAMETER MAX UNIT/WR Thermal Resistance, Junctio
