View irfz44ns datasheet:

irfz44nsirfz44ns

isc N-Channel MOSFET Transistor IRFZ44NSFEATURESWith TO-263( D2PAK ) packagingHigh speed switchingLow gate input resistanceStandard level gate driveEasy to use100% avalanche testedMinimum Lot-to-Lot variations for robust deviceperformance and reliable operationAPPLICATIONSPower supplySwitching applicationsABSOLUTE MAXIMUM RATINGS(T =25)aSYMBOL PARAMETER VALUE UNITV Drain-Source Voltage 55 VDSSV Gate-Source Voltage 20 VGSSDrain Current-Continuous;Tc=2549I ADTc=10035I Drain Current-Single Pulsed 160 ADMP Total Dissipation 94 WDT Operating Junction Temperature 175 jStorage Temperature -55~175 TstgTHERMAL CHARACTERISTICSSYMBOL PARAMETER MAX UNIT/WRth(ch-c) Channel-to-case thermal resistance 1.5/WRth(ch-a) Channel-to-ambient thermal resistance 401isc website
