View irg7s313u datasheet:
PD - 97402AIRG7S313UPbFPDP TRENCH IGBTKey ParametersFeaturesVCE min 330 Vl Advanced Trench IGBT Technologyl Optimized for Sustain and Energy RecoveryVCE(ON) typ. @ IC = 20A 1.35 Vcircuits in PDP applicationsIRP max @ TC= 25C 160 Al Low VCE(on) and Energy per Pulse (EPULSETM)TJ max 150 Cfor improved panel efficiencyl High repetitive peak current capabilityl Lead Free packageCECGGD2PakEIRG7S313UPbFn-channelGC EGate Collector EmitterDescriptionThis IGBT is specifically designed for applications in Plasma Display Panels. This device utilizes advancedtrench IGBT technology to achieve low VCE(on) and low EPULSETM rating per silicon area which improve panelefficiency. Additional features are 150C operating junction temperature and high repetitive peak currentcapability. These features combine to make this IGBT a highly effic
