View irg7sc28u datasheet:
PD - 97569APDP TRENCH IGBTIRG7SC28UPbFKey ParametersFeaturesVCE min600 Vl Advanced Trench IGBT TechnologyVCE(ON) typ. @ IC = 40A1.70 Vl Optimized for Sustain and Energy Recoverycircuits in PDP applicationsIRP max @ TC= 25C 225 Al Low VCE(on) and Energy per Pulse (EPULSETM)TJ max150 Cfor improved panel efficiencyl High repetitive peak current capabilityl Lead Free packageCCECGGD2PakEIRG7SC28UPbFn-channelG C EGate Collector EmitterDescriptionThis IGBT is specifically designed for applications in Plasma Display Panels. This device utilizes advancedtrench IGBT technology to achieve low VCE(on) and low EPULSETM rating per silicon area which improve panelefficiency. Additional features are 150C operating junction temperature and high repetitive peak currentcapability. These features combine to make this IGBT a hig
