All Transistors. Datasheet



View irgp4760 datasheet:

irgp4760irgp4760

IRGP4760PbF IRGP4760-EPbF Insulated Gate Bipolar Transistor VCES = 650V CIC = 60A, TC =100C tSC 5.5s, TJ(max) = 175C GE E C C G G EVCE(ON) typ. = 1.7V @ IC = 48A IRGP4760PbFIRGP4760EPbFn-channelTO247ACTO247ADApplications G C E Industrial Motor Drive Gate Collector Emitter UPS Solar Inverters Welding Features Benefits Low VCE(ON) and Switching Losses High Efficiency in a Wide Range of Applications 5.5s Short Circuit SOA Rugged Transient Performance Square RBSOA Maximum Junction Temperature 175C Increased ReliabilityPositive VCE (ON) Temperature Coefficient Excellent Current Sharing in Parallel Operation Lead-Free, RoHs compliant Environmentally friendly Base part number Package Type Standard Pack Orderable Part Number Form Quantity IRGP4760PbF TO-247AC Tube 25 IR
