View j111 j112 datasheet:

J111, J112JFET Chopper TransistorsN-Channel DepletionFeatureshttp://onsemi.com Pb-Free Packages are Available*1 DRAINMAXIMUM RATINGSRating Symbol Value Unit3Drain-Gate Voltage VDG -35 VdcGATEGate -Source Voltage VGS -35 VdcGate Current IG 50 mAdc2 SOURCETotal Device Dissipation @ TA = 25C PD 350 mWDerate above = 25C 2.8 mW/CLead Temperature TL 300 COperating and Storage Junction TJ, Tstg -65 to +150 CTemperature RangeMaximum ratings are those values beyond which device damage can occur.TO-92Maximum ratings applied to the device are individual stress limit values (notCASE 29-11normal operating conditions) and are not valid simultaneously. If these limits are1STYLE 5exceeded, device functional operation is not implied, damage may occur and23reliability may be affected.MARKING DIAGRAMJ11xAYWW GGJ11x =
