View j310 datasheet:

j310j310

Discrete POWER & SignalTechnologiesJ309 MMBFJ309J310 MMBFJ310GDG TO-92S SOT-23 SDMark: 6U / 6TN-Channel RF AmplifierThis device is designed for VHF/UHF amplifier, oscillator and mixerapplications. As a common gate amplifier, 16 dB at 100 MHz and12 dB at 450 MHz can be realized. Sourced from Process 92.Absolute Maximum Ratings* TA = 25C unless otherwise notedSymbol Parameter Value UnitsVDS Drain-Source Voltage 25 VVGS Gate-Source Voltage - 25 VIGF Forward Gate Current 10 mAOperating and Storage Junction Temperature Range -55 to +150TJ ,Tstg C*These ratings are limiting values above which the serviceability of any semiconductor device may be impaired.NOTES:1) These ratings are based on a maximum junction temperature of 150 degrees C.2) These are steady state limits. The factory should be consulted on applications involving pulsed or lo
