View je13007 datasheet:

Inchange Semiconductor Product Specification Silicon NPN Power Transistors MJE13007 DESCRIPTION With TO-220C package High voltage ,high speed APPLICATIONS Particularly suited for 115V and 220V switchmode applications such as switching regulators,inverters ,motor controls,solenoid/ relay drivers and deflection circuits PINNING PIN DESCRIPTION1 Base Collector;connected to 2 mounting base 3 EmitterAbsolute maximum ratings(Tc=25) SYMBOL PARAMETER CONDITIONS VALUE UNITVCBO Collector-base voltage Open emitter 700 V VCEO Collector-emitter voltage Open base 400 V VEBO Emitter-base voltage Open collector 9 V IC Collector current (DC) 8 A ICM Collector current-Peak 16 AIB Base current 4 AIBM Base current-Peak 8 AIE Emitter current 12 AIEM Emitter current-Peak 24 APD Total power dissipation TC=25 80 W Tj Junction tempera
