View jfam20n60c datasheet:

JFAM20N60C 600V N-Channel MOSFET General Description This Power MOSFET is produced using advanced planar stripe DMOS technology. This advanced technology has been especially tailored to minimize on-state resistance, provide superior switching performance, and withstand high energy pulse in the avalanche and commutation mode. These devices are well suited for high efficiency switched mode power supplies, active power factor correction based on half bridge topology. Features 20A, 600V, RDS(on)typ. = 0.35@VGS = 10 V Low gate charge (50nC) High ruggedness Fast switching 100% avalanche tested Improved dv/dt capability Absolute Maximum Ratings TC = 25 unless otherwise noted Symbol Parameter JFAM20N60C Units VDSS Drain Source Voltage 600 V 20* A Continuous ( TC = 25 ) ID Drain Current Continuous ( TC = 100 ) 12.5* A
