View ksc1815 datasheet:

KSC1815Audio Frequency Amplifier & High Frequency OSC Complement to KSA1015 Collector-Base Voltage : VCBO= 50VTO-9211. Emitter 2. Collector 3. BaseNPN Epitaxial Silicon TransistorAbsolute Maximum Ratings Ta=25C unless otherwise noted Symbol Parameter Value UnitsVCBO Collector-Base Voltage 60 VVCEO Collector-Emitter Voltage 50 VVEBO Emitter-Base Voltage 5 VIC Collector Current 150 mAIB Base Current 50 mAPC Collector Power Dissipation 400 mWTJ Junction Temperature 125 CTSTG Storage Temperature -55 ~ 150 CElectrical Characteristics Ta=25C unless otherwise noted Symbol Parameter Test Condition Min. Typ. Max. UnitsICBO Collector Cut-off Current VCB=60V, IE=0 0.1 AIEBO Emitter Cut-off Current VEB=5V, IC=0 0.1 AhFE1 DC Current Gain VCE=6V, IC=2mA 70 700hFE2 VCE=6V, IC=150mA 25VCE (sat) Collector-Emitter Saturation Voltage IC
