View ktc9015sc datasheet:

SEMICONDUCTOR KTC9015SCTECHNICAL DATA EPITAXIAL PLANAR PNP TRANSISTORGENERAL PURPOSE APPLICATION. SWITCHING APPLICATION.FEATURESExcellent hFE Linearity: hFE(IC=-0.1mA)/hFE(IC=-2mA)=0.95(Typ.).Complementary to KTC9014SC.MAXIMUM RATING (Ta=25)CHARACTERISTIC SYMBOL RATING UNITVCBO -70 VCollector-Base VoltageVCEO -50 VCollector-Emitter VoltageVEBOEmitter-Base Voltage -5 VICCollector Current -100 mAPC *Collector Power Dissipation 350 mWTjJunction Temperature 150Tstg -55150 Storage Temperature Range* PC : Package Mounted On 99.5% Alumina (1080.6)ELECTRICAL CHARACTERISTICS (Ta=25)CHARACTERISTIC SYMBOL TEST CONDITION MIN. TYP. MAX. UNITV(BR)CBO IC=-0.05mA, IE=0Collector-Base Breakdown Voltage -70 - - VV(BR)CEO IC=-1mA, IB=0Collector-Emitter Breakdown Voltage -50 - - VV(BR)EBO IE=-0.05mA, IC=0Emitter-Ba
