Order this documentMOTOROLAby MJE13002/DSEMICONDUCTOR TECHNICAL DATA*MJE13002MJE13003*Designer's Data Sheet*Motorola Preferred DeviceSWITCHMODE Series1.5 AMPERENPN SILICONNPN Silicon Power TransistorsPOWER TRANSISTORS300 AND 400 VOLTSThese devices are designed for highvoltage, highspeed power switching40 WATTSinductive circuits where fall time is critical. They are particularly suited for 115 and220 V SWITCHMODE applications such as Switching Regulators, Inverters, MotorControls, Solenoid/Relay drivers and Deflection circuits.SPECIFICATION FEATURES: Reverse Biased SOA with Inductive Loads @ TC = 100_C Inductive Switching Matrix 0.5 to 1.5 Amp, 25 and 100_C. . . tc @ 1 A, 100_C is 290 ns (Typ). 700 V Blocking Capability SOA and Switching Applications Information.
