View mje13002 datasheet:

UNISONIC TECHNOLOGIES CO., LTD MJE13002 NPN EPITAXIAL SILICON TRANSISTOR HIGH VOLTAGE FAST-SWITCHING NPN POWER TRANSISTOR DESCRIPTION The UTC MJE13002 designed for use in highvolatge,high speed,power switching in inductive circuit, It is particularly suited for 115 and 220V switchmode applications such as switching regulators,inverters, DC-DC converter, Motorcontrol, Solenoid/Relay drivers and deflection circuits. FEATURES *Collector-Emitter Sustaining Voltage: VCEO (sus)=300V. *Collector-Emitter Saturation Voltage: VCE(sat)=1.0V(Max.) @Ic=1.0A, IB =0.25A *Switch Time- tf =0.7s(Max.) @Ic=1.0A. ORDERING INFORMATION Ordering Number Pin Assignment Package Packing Lead Free Halogen Free 1 2 3MJE13002L-x-T92-B MJE13002G-x-T92-B TO-92 B C E Tape BoxMJE13002L-x-T92-K MJE13002G-x-T92-K TO-92 B C E BulkMJE13002L-x-T92-R MJE13002G-x-
