View mje13003d datasheet:

UNISONIC TECHNOLOGIES CO., LTD MJE13003D NPN SILICON TRANSISTOR HIGH VOLTAGE FAST-SWITCHING NPN POWER TRANSISTOR DESCRIPTION The UTC MJE13003D is a NPN Power Transistor. It is intended to be used in applications requiring medium voltage capability and high switching speeds. FEATURES * Fast-Switching And High Voltage Capability * Dynamic Parameters With Low Spread * High Reliability * Integrated Antiparallel Collector-Emitter Diode INTERNAL SCHEMATIC DIAGRAM C (2)B (1)E (3) ORDERING INFORMATION Ordering Number Pin Assignment Package Packing Lead Free Halogen Free 1 2 3 MJE13003DL-x-TA3-T MJE13003DG-x-TA3-T TO-220 B C E TubeMJE13003DL-x-T60-K MJE13003DG-x-T60-K TO-126 B C E BulkMJE13003DL-x-T92-B MJE13003DG-x-T92-B TO-92 B C E Tape BoxMJE13003DL-x-T92-K MJE13003DG-x-T92-K TO-92 B C E BulkMJE13003DL-x-T92-R MJE13003DG-x-T
