Inchange Semiconductor Product Specification Silicon NPN Power Transistors MJE13005 DESCRIPTION With TO-220C package High voltage ,high speed APPLICATIONS Particularly suited for 115V and 220V switchmode applications such as switching regulators,inverters ,motor controls,solenoid/ relay drivers and deflection circuits PINNING PIN DESCRIPTION1 Base Collector;connected to 2 mounting base 3 EmitterAbsolute maximum ratings (Tc=25) SYMBOL PARAMETER CONDITIONS VALUE UNITVCBO Collector-base voltage Open emitter 700 V VCEO Collector-emitter voltage Open base 400 V VEBO Emitter-base voltage Open collector 9 V IC Collector current 4 A ICM Collector current-Peak 8 AIB Base current 2 AIBM Base current-PeaK 4 AIE Emitter current 6 AIEM Emitter current-Peak 12 ATa=25 2 PD Total power dissipation W TC=25 75 Tj Junction
