Order this documentMOTOROLAby MJE13005/DSEMICONDUCTOR TECHNICAL DATA*MJE13005*Motorola Preferred DeviceDesigner's Data Sheet4 AMPERESWITCHMODE SeriesNPN SILICONPOWER TRANSISTORNPN Silicon Power Transistors400 VOLTSThese devices are designed for highvoltage, highspeed power switching 75 WATTSinductive circuits where fall time is critical. They are particularly suited for 115 and220 V SWITCHMODE applications such as Switching Regulators, Inverters, MotorControls, Solenoid/Relay drivers and Deflection circuits.SPECIFICATION FEATURES: VCEO(sus) 400 V Reverse Bias SOA with Inductive Loads @ TC = 100_C Inductive Switching Matrix 2 to 4 Amp, 25 and 100_C. . . tc @ 3A, 100_C is 180 ns (Typ) 700 V Blocking Capability SOA and Switching Applications Information.CASE 221A06
