View mje13007 datasheet:

mje13007mje13007

Order this documentMOTOROLAby MJE13007/DSEMICONDUCTOR TECHNICAL DATAMJE13007MJF13007Designer's Data SheetSWITCHMODENPN Bipolar Power TransistorPOWER TRANSISTORFor Switching Power Supply Applications8.0 AMPERES400 VOLTSThe MJE/MJF13007 is designed for highvoltage, highspeed power switching80/40 WATTSinductive circuits where fall time is critical. It is particularly suited for 115 and 220 Vswitchmode applications such as Switching Regulators, Inverters, Motor Controls,Solenoid/Relay drivers and Deflection circuits. VCEO(sus) 400 V Reverse Bias SOA with Inductive Loads @ TC = 100C 700 V Blocking Capability SOA and Switching Applications Information Two Package Choices: Standard TO220 or Isolated TO220 MJF13007 is UL Recognized to 3500 VRMS, File #E69369MAXIMUM RATINGSRating Symbol MJE13007 MJF13007 Unit
