View mje13009-3pn datasheet:
SavantIC Semiconductor Product Specification Silicon NPN Power Transistors MJE13009 DESCRIPTION With TO-3PN package High voltage ,high speed APPLICATIONS Particularly suited for 115V and 220V switchmode applications such as switching regulators,inverters ,motor controls,solenoid/ relay drivers and deflection circuits PINNING PIN DESCRIPTION1 Base Collector;connected to 2mounting base Fig.1 simplified outline (TO-3PN) and symbol 3 Emitter Absolute maximum ratings(Tc=25 )SYMBOL PARAMETER CONDITIONS VALUE UNITV Collector-base voltage Open emitter 700 V CBOV Collector-emitter voltage Open base 400 V CEOVEBO Emitter-base voltage Open collector 9 V I Collector current (DC) 12 A CI Collector current-Peak 24 ACMIE Emitter current 18 A I Emitter current-Peak 36 AEMI Base current 6 A BIBM Base current-Peak 12 AT =25
