View mje13009-p datasheet:

UNISONIC TECHNOLOGIES CO., LTD MJE13009-P NPN SILICON TRANSISTOR SWITCHMODE SERIES NPN SILICON POWER TRANSISTORS DESCRIPTION The MJE13009-P is designed for high-voltage, high-speedpower switching inductive circuits where fall time is critical. They are particularly suited for 115 and 220V switch mode applications such as Switching Regulators, Inverters, Motor Controls,Solenoid/Relay drivers and Deflection circuits. FEATURES * VCEO 400V and 300 V * Reverse Bias SOA with Inductive Loads @ TC = 100C * Inductive Switching Matrix 3 ~ 12 Amp, 25 and 100C tC @ 8 A, 100C is 120 ns (Typ). * 700 V Blocking Capability * SOA and Switching Applications Information. ORDERING INFORMATION Ordering Number Pin Assignment Package Packing Lead Free Halogen Free 1 2 3 MJE13009L-P-T3P-T MJE13009G-P-T3P-T TO-3P B C E Tube MJE13009L-P-TA3-T MJE13009G-
