View mje13009 datasheet:

MJE13009SILICON NPN SWITCHING TRANSISTOR SGS-THOMSON PREFERRED SALESTYPEDESCRIPTIONThe MJE13009 is a multiepitaxial mesa NPNtransistor. It is mounted in Jedec TO-220 plasticpackage, intended for use in motor controls,switching regulators, deflection circuits, etc.321TO-220INTERNAL SCHEMATIC DIAGRAMABSOLUTE MAXIMUM RATINGSSymbol Parameter Value UnitVCEO Collector-Emitter Voltage (IB = 0) 400 VV Collector-Emitter Voltage (V = -1.5 V) 700 VCEV BEV Emitter-Base Voltage (I = 0) 9 VEBO CIC Collector Current 12 AICM Collector Peak Current (tp 10 ms) 24 AI Base Current 6 ABI Base Peak Current (t 10 ms) 12 ABM pI Emitter Current 18 AEIEM Emitter Peak Current 36 AoPtot Total Power Dissipation at Tc 25 C 100 WoT Storage Temperature -65 to 150 CstgoT Max. Operating Junction Temperature 150 Cj1/6September 1997
