View mje13009zj datasheet:

mje13009zjmje13009zj

MJE13009ZJ(BR3DD13009ZJ) Rev.C Feb.-2015 DATA SHEET / Descriptions TO-220S NPN Silicon NPN transistor in a TO-220S Plastic Package. / Features High VCEO High IC. / Applications High frequency electronic lighting ballast applications. / Equivalent Circuit / Pinning 4 1 2 3 PIN1Base PIN 2Collector PIN 3Emitter PIN 4NC / hFE Classifications & Marking See Marking Instructions.http://www.fsbrec.com 1 / 6 MJE13009ZJ(BR3DD13009ZJ) Rev.C Feb.-2015 DATA SHEET / Absolute Maximum Ratings(Ta=25) Parameter Symbol Rating Unit Collector to Base Voltage VCBO 700 VCollector to Emitter Voltage VCEO 450 VEmit
