View mmbfj309 mmbfj310 datasheet:

MOTOROLAOrder this documentSEMICONDUCTOR TECHNICAL DATAby MMBFJ309LT1/DJFET VHF/UHF Amplifier TransistorMMBFJ309LT1NChannel2 SOURCEMMBFJ310LT13GATE1 DRAIN31MAXIMUM RATINGS2Rating Symbol Value UnitDrainSource Voltage VDS 25 VdcCASE 31808, STYLE 10GateSource Voltage VGS 25 Vdc SOT23 (TO236AB)Gate Current IG 10 mAdcTHERMAL CHARACTERISTICSCharacteristic Symbol Max UnitTotal Device Dissipation FR5 Board(1) PD 225 mWTA = 25CDerate above 25C 1.8 mW/CThermal Resistance, Junction to Ambient RqJA 556 C/WJunction and Storage Temperature TJ, Tstg 55 to +150 CDEVICE MARKINGMMBFJ309LT1 = 6U; MMBFJ310LT1 = 6TELECTRICAL CHARACTERISTICS (TA = 25C unless otherwise noted)Characteristic Symbol Min Typ Max UnitOFF CHARACTERISTICSGateSource Breakdown Voltage (IG = 1.0 Adc, VDS = 0) V(BR)GSS 25
