View mmbt9015-b mmbt9015-c mmbt9015-d datasheet:

MMBT9015 PNP Transistor FeaturesSOT-23 (TO-236) For Switching and Amplifier Applications. As Complementary Type of the PNP TransistorMMBT9014 is Recommended.1.Base 2.Emitter 3.CollectorAbsolute Maximum Ratings Ratings at 25 ambient temperature unless otherwise specified. Parameter Symbol Value UnitCollector Base Voltage -V 50 V CBOCollector Emitter Voltage -V 45 V CEOEmitter Base Voltage -V 5 V EBOCollector Current -I 100 mA CPower Dissipation P 200 mW DJunction Temperature T 150 J Storage Temperature Range T -55 to 150 STGElectrical Characteristics Ratings at 25 ambient temperature unless otherwise specified. Parameter Symbol Min. Typ. Max. Unit DC Current Gain 110 - 220 at -VCE = 5 V, -IC = 1 mA Current Gain Group B HFE C 200 - 450 D 420 - 800 Collector Base Cutoff Current -I - - 50 nA
