View mmbtsc4098w datasheet:

MMBTSC4098W NPN Silicon Epitaxial Planar Transistor for AM/FM amplifier and local oscillator of FM/VHF tuner applications. OAbsolute Maximum Ratings (Ta = 25 C) Parameter Symbol Value UnitCollector Base Voltage VCBO 40 VCollector Emitter Voltage VCEO 25 VEmitter Base Voltage VEBO 5 VCollector Current IC 50 mA Power Dissipation Ptot 200 mWOJunction Temperature Tj 150 C OStorage Temperature Range Tstg - 55 to + 150 C OCharacteristics at Ta = 25 C Parameter Symbol Min. Typ. Max. UnitDC Current Gain hFE 82 - 180at VCE = 6 V, IC = 1 mA - Collector Cutoff Current ICBO - - 0.5 A at VCB = 24 V Emitter Cutoff Current IEBO - - 0.5 Aat VEB = 3 V Collector Base Breakdown Voltage V(BR)CBO 40 - - V at IC = 50 A Collector Emitter Breakdown Voltage V(BR)CEO 25 - - V at IC = 1 mA Emitter Base Breakdown Voltage V(BR)EBO 5 -
