View mmdt3906 datasheet:

MMDT3906DUAL PNP GENERAL PURPOSE SWITCHING TRANSISTOR 40 Volt POWER 200 mWattVOLTAGEFEATURES PNP epitaxial silicon, planar design Collector-emitter voltage VCE = -40V Collector current IC = -200mA Lead free in compliance with EU RoHS 2011/65/EU directive Green molding compound as per IEC61249 Std. . (Halogen Free)MECHANICAL DATA Case: SOT-363, Plastic Terminals: Solderable per MIL-STD-750, Method 2026 Approx. Weight: 0.0002 ounces, 0.006 grams. Marking: S2A6 5 41 2 3Fig.53ABSOLUTE RATINGSPARAMETER Symbol Value UnitsCollector - Emitter Voltage VCEO -40 VCollector - Base Voltage VCBO -40 VEmitter - Base Voltage VEBO -5.0 VCollector Current - Continuous I C -200 mATHERMAL CHARACTERISTICSPARAMETER Symbol Value UnitsMax Power Dissipation (Note 1) PTOT 200 mWOThermal Resistance , Junction to Ambient RJA 62
